Power Supply|XILENCE|1250 Watts|Efficiency 80 PLUS GOLD|PFC Active|XN178

  • Produkta kods: XN178
  • EAN: 4044953503511
  • Stāvoklis: Jauns
CenaSkaitsPiegāde

207.62

171.59 € (bez PVN 21%)

3

23.04.

Apraksts

The fully modular power supplies of the X+ series are capable of absorbing high load peaks above the normal rated power in the shortest possible time and comply with Intel\'s Design Guide 3.0. Thus, the power supplies are ideally
suited for driving the latest and most powerful gaming graphics cards with PCI Express 5 specifications. An 80+ Gold certification confirms a high efficiency and energy efficiency of this power supply series. Six different protection circuits (OCP, OVP, UVP, SCP, OPP, OTP) ensure safe operation even in heated gaming sessions. The fans of the ATX 3.0 power supplies run with Fluid Dynamic Bearing technology and are very quiet. In addition, they convince with an extremely long durability and their excellent cooling performance. All of these specifications make the affordable Performance X+ series ideal for use with the latest gaming PC systems.

Šim produktam ir 24 mēnešu garantija.

Parametri

SummaryXilence XP1250MR9.2. Total power: 1250 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 65 cm, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Red, Cooling type: Active, Fan diameter: 14 cm. Compliance certificates: RoHS, WEEE
Ražotājs datu lapahttps://www.xilence.net/en/power-supplies/235
CnCode85044095
Vienība kastes augstums0.097
Vienība kastes garums0.33
Vienība kastes platums0.19
Ievades frekvence50/60 Hz
Ieejas spriegums100 - 240 V
Efektivitāte89 %
Ieejas strāva15 A
Max izejas strāva (+12V)104.1 A
Max izejas strāva (+3.3V)20 A
Max izejas strāva (+5V)20 A
Max izejas strāva (+5Vsb)3 A
Max izejas strāva (-12V)0.3 A
Barošanas faktors korekcija (PFC) tipsActive
Barošanas aizsardzība funkcijasOver current/Over power/Over voltage/Short circuit/Under voltage
Kopējais barošanas1250 W
Kabeļu veidsFully-Modular
Centrālā procesora barošanas savienotājs (4+4 kontakti)Yes
Motherboard barošanas kabeļa garums650 mm
Motherboard barošanas savienotājs20+4 pin ATX
Numurs of SATA barošanas savienotāji12
PCI Express jauda connectors (6+2 pin)3
PCI Express jauda connectors (8-pin)1
80 plus sertifikācija80 PLUS Gold
ATX versija3.0
Gultņu tehnoloģijaFDB
Barošanas barošana vienība (PSU) formas faktorsATX
MērķisPC
Dzesēšanas tipsActive
Ventilatora diametrs140 mm
Numurs Of Fans1 fan(s)
Produkts krāsaBlack/Red
Atbilstības sertifikātiRoHS/WEEE
Dziļums180 mm
Augstums86 mm
Platums150 mm
Iepakojums tipsBox
Sustainability certificatesErP
Sustainability complianceYes
Modelis NosaukumsXP1250MR9.2
Vienības uz piegāde kastes1
Vienība Calculated skaļums0.006082 cubm
Vienība Calculated svars3.33 kg
