NET VIDEO RECORDER 8CH 8POE/NVR4108HS-8P-4KS3 DAHUA

  • Produkta kods: DHI-NVR4108HS-8P-4KS3
  • EAN: 6923172573827
  • Stāvoklis: Jauns
CenaSkaitsPiegāde

426.15

352.36 € (bez PVN 21%)

6

23.07.

Apraksts

The NVR4000-4KS3 model of the Lite Series NVR is favored for its outstanding performance. It supports 4K resolution for scenes that require highly detailed images, and can serve as the edge, central, or backup storage with an intuitive shortcut menu for remote management and control. This NVR also features Smart Motion Detection (SMD) by recorder, which can distinguish target vehicles and humans from ordinary ones in real-time. When an IPC is connected to the NVR, a variety of AI functions become available such as face detection, perimeter protection, and people counting. This NVR is both cost-effective and easy-to-install, making it ideal for a wide range of applications such as for cities, transportation, education and finance

  • Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats
  • Max. decoding capability: 8 × 1080p@30 fps
  • Max. 160/160/80 Mbps incoming/recording/outgoing bandwidth
  • Supports IP cameras with a resolution up to 12 MP
  • AI by Recorder supports 4-channel SMD Plus
  • AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, people counting, stereo analysis and heat map
  • Supports EPTZ, and one-click arming and disarming

Šim produktam ir 36 mēnešu garantija.

Parametri

Garš aprakstsDahua Technology DHI-NVR4108HS-8P-4KS3. Maximum resolution: 3840 x 2160 pixels, Number of simultaneously playbacked channels: 8 channels, Video recording modes: 720p, 1080p, 2160p. Maximum storage capacity: 20 TB, HDD interface: SATA. Ethernet LAN data rates: 10,100,1000 Mbit/s, Audio output: 1-channel RCA, Networking standards: IEEE 802.3af, IEEE 802.3at. Rack capacity: 1U, Product colour: Black, Certification: CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021;.... Display diagonal: 2.54 cm (1")
Ražotāja datu lapahttps://www.dahuasecurity.com/fr/products/All-Products/Network-Recorders/Lite-Series/NVR4-4KS3-Series/1HDD/NVR4108HS-8P-4KS3
Uzskaitījuma punkti
  • Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats
  • Max. decoding capability: 8 × 1080p@30 fps
  • Max. 160/160/80 Mbps incoming/recording/outgoing bandwidth
  • Supports IP cameras with a resolution up to 12 MP
  • AI by Recorder supports 4-channel SMD Plus
  • AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, people counting, stereo analysis and heat map
  • Supports EPTZ, and one-click arming and disarming
ModelisDHI-NVR4108HS-8P-4KS3
Modeļa nosaukumsDHI-NVR4108HS-8P-4KS3
Iebūvēts procesorsYes
Ethernet LAN (RJ-45) pieslēgvietas1
Atbalstīto HDD skaits1
Ethernet LAN datu pārraides ātrums10/100/1000 Mbit/s
Barošana caur Ethernet (PoE)Yes
PoE portu skaits8
product_attr.NUMBER_OF_SIMULTANEOUSLY_PLAYBACKED_CHANNELS8 channels
Video ierakstīšanas režīmi1080p/2160p/720p
Maksimālā glabāšanas ietilpība20 TB
Maksimālā izšķirtspēja3840 x 2160 pixels
Atbalstītā izšķirtspēja3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
HDD interfeissSATA
HDMI portu skaits1
Statīva montāžaYes
USB 2.0 portu skaits2
VGA (D-Sub) izejas porti1
Statīva ietilpība1U
product_attr.AUDIO_RCA_INPUTS1
product_attr.AUDIO_RCA_OUTPUTS1
Platums260 mm
Dziļums232.5 mm
Augstums47.6 mm
product_attr.PEOPLE_COUNTINGYes
Svars920 g
Video kustības noteikšanaYes
Atbalstītās mobilās operētājsistēmasAndroid/iOS
Video signāla zuduma noteikšanaYes
Vairāki ekrāniYes
Darbības temperatūra (T-T)-10 - 55 °C
Atbalstītā pārlūkprogrammaChrome; IE; Safari; Edge; Firefox
Darbības relatīvais mitrums (H-H)10 - 93 %
Atbalstītie audio formātiG.711 µ-law/G.711 A-law/G.726/PCM
Atbalstītie video formātiH.264/H.265/H.265+/MJPG
Instalētā operētājsistēmaEmbedded LINUX
Izejas strāva1.81 A
Izejas spriegums53 V
PoE jauda uz portu25.5 W
Kopējais Power over Ethernet (PoE) budžets72 W
Iebūvēts displejsNo
Displeja diagonāle1 "
Produkta krāsaBlack
Audio izvade1-channel RCA
Audio kodekiG.711a; G.711u; PCM; G726
product_attr.INPUT_BANDWIDTH160 Mbit/s
Maksimālais kadra ātrums30 fps
product_attr.OUTPUT_BANDWIDTH80 Mbit/s
MomentuzņēmumsYes
product_attr.VIDEO_CODECSSmart H.265+; H.265; Smart H.264+; H.264
Tīklošanas standartiIEEE 802.3af/IEEE 802.3at
Iepakojuma platums374 mm
Glabāšanas temperatūra (T-T)-20 - 60 °C
Iepakojuma dziļums119 mm
Atbalstītie tīkla protokoliHTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)
Iepakojuma augstums311 mm
Sejas noteikšanaYes
Iepakojuma svars2050 g
SertifikācijaCE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014
Vienības paletē0
Vienības piegādes kastē10
Vienības aprēķinātais tilpums0.01505 cubm
Vienības aprēķinātais svars2.2 kg
